SKU: UCFL324D1-NTN

NTN UCFL324D1 Metric Two Bolt Oval Cast Iron Flange Housing with 120mm Bore Insert - Allow 2-3 Days

NTN UCFL324D1 Metric Two Bolt Oval Cast Iron Flange Housing with 120mm Bore Insert - Allow 2-3 Days

Out of stock


Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Dimensions
Shaft diameter 120mm
H 520mm
J 430mm
A<sub>2</sub> 65mm
A<sub>1</sub> 48mm
A 110mm
N 47mm
L 330mm
A<sub>0</sub> 140mm
B 126mm
S 51mm
Fixing bolt M42
--- Load rating
Dynamic load C<sub>r</sub> 229 kN
Static load C<sub>0r</sub> 185 kN
Fatigue load limit C<sub>u</sub> 10.5 kN
--- Unit information
Mass 48 kg
