SKU: UC.210-32.TS.CHAL
Challenge UC210-32 Imperial Insert with Grub Screws with 2 inch Bore 90mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Challenge UC210-32 Imperial Insert with Grub Screws with 2 inch Bore 90mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Out of stock
Description
Description
UC Insert with Grub Screws: These normal-duty bearing units are fitted with a triple lip seal. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. Also available as a complete housing assembly.
Benefits: High tolerance to harsh environments, cost effective bearing, re-lubricatable, grub screw fixing
- Brand / Quality:
- Challenge - Good Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- UC
Technical
Technical
| Shaft Diameter d | 2 inch |
|---|---|
| Outside Diameter D | 90mm |
| Overall Width Bi | 51.6mm |
| Inner Race Width Be | 24mm |
| Back of Bearing to Centre Line n | 19mm |
| Front of Bearing to Centre Line m | 32.6mm |
| Dimension G | 10mm |
| Grub Screws x 2 | 3/8 - 24UNF inch |
| Load Rating (Dynamic) | 2750kg |
| Load Rating (Static) | 2020kg |
| Max Speed | 1800 rev/min |
| Grease Nipple Thread Size | M8 |
| Working Temperature | -30°C to +120°C |
