SKU: TSFL5C-ISB
ISB TSFL5C Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M5 Thread
ISB TSFL5C Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M5 Thread
Equivalent to: TSFL5C
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M5x0.8
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Bore:
- 5
- Inside Diameter:
- 5
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 5mm |
|---|---|
| d1 | 7.7mm |
| d2 | 18mm |
| d3 | M 5x0.8mm |
| d4 | 9mm |
| d5 | 12mm |
| dk | 11.11mm |
| B | 8mm |
| C1 | 7.5mm |
| D | 13mm |
| h1 | 27mm |
| I3 | 8mm |
| I4 | 36mm |
| I5 | 4mm |
| I7 | 10mm |
| W | 10mm |
| α | 13° |
| r 1s min | 0.3Nmax Min -1 |
| Dynamic C | 3.6KN |
| Static C0 | 4.6KN |
| Weight | 0.01Kg |
