• SS20DP/14B-0.3125 Imperial EN8 Steel Spur Gear 14 Tooth 20 DP Bored 0.3125 inch (H8)
1 1

SKU: SS20DP/14B-0.3125_INCH

SS20DP/14B-0.3125 Imperial EN8 Steel Spur Gear 14 Tooth 20 DP Bored 0.3125 inch (H8)

SS20DP/14B-0.3125 Imperial EN8 Steel Spur Gear 14 Tooth 20 DP Bored 0.3125 inch (H8)
$73.16 ex VAT
$73.16 ex VAT
Sale Sold out

In stock

Price Break
5+ $34.70
9+ $32.75
19+ $32.36
29+ $31.97
49+ $31.58
74+ $31.19
99+ $29.24
199+ $28.85
249+ $28.46
499+ $28.07
999+ $27.29

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
GEAR_IMP_S_DESC
Brand / Quality:
Drive-Flex - High Quality
Bore:
7.93mm = 0.312 (5/16) inch
Number of Teeth:
14
Variant:
Tooth Profile B
Pitch Circle Diameter:
17.78mm = 0.7 inch
Gear Modulus:
20DP
Technical
Number of Teeth 14
Pitch (dp) 0.7 inch
Bore (H8) 0.3125 inch
Hub / Boss (dm) 0.5 inch
Outside (de) 0.8 inch
Width (A) 0.75 inch
Face Width (B) 0.375 inch
Modulus / Diametral Pitch DP 20 dp
Tolerance unless otherwise stated +- 0.01 inch
Pressure Angle 20 degrees
