SKU: SIL80TXE-2LS-SKF
SKF SIL80TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M80x4 Thread
SKF SIL80TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Female Rod End M80x4 Thread
Out of stock
Description
Description
- Brand / Quality:
- SKF - High Quality
- Thread Size:
- M80x4
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Inside Diameter:
- 80mm
- Material:
- PTFE Fabric Lined
Technical
Technical
| d | 80mm |
|---|---|
| d2 max | 182mm |
| G 6H | M80x4 |
| B | 55mm |
| C1 max | 48mm |
| h1 | 295mm |
| a | 6deg |
| Dynamic load C | 1140 kN |
| Static load Co | 655 kN |
| Weight | 19 kg |
| dk | 105mm |
| d4 | 105mm |
| l3 min | 85mm |
| l4 max | 389mm |
| l5 | 40mm |
| l7 min | 98mm |
| r1 min | 1mm |
| w h14 | 90mm |
