• RHP MST1-3/4 Cast Iron Take Up Unit and 1-3/4 inch Bore Insert
1 1

SKU: MST1.3/4-RHP

RHP MST1-3/4 Cast Iron Take Up Unit and 1-3/4 inch Bore Insert

RHP MST1-3/4 Cast Iron Take Up Unit and 1-3/4 inch Bore Insert
$265.27 ex VAT
$265.27 ex VAT
Sale Sold out

In stock

Price Break
10+ $125.95
20+ $118.88
30+ $117.46
40+ $116.05
50+ $114.63
75+ $113.21
100+ $106.14
200+ $104.72
250+ $103.31
500+ $101.89
1000+ $99.06

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
RHP - High Quality
Inside Diameter:
44.45mm = 1.75 (1-3/4) inch
Style:
MST
Technical
Bore 1-3/4 inch
L 5.945 inch
L1 3.563 inch
L2 0.61 inch
L3 0.807 inch
L4 3.209 inch
L5 1.988 inch
H 4.646 inch
H1 3.248 inch
H2 1.949 inch
H3 3.976 inch
N 1.142 inch
A 1.949 inch
A1 1.457 inch
A2 0.689 inch
B 2.031 inch
B5 - inch
s 0.752 inch
d1 2.449 inch
d4 - inch
Dynamic load 35000 N
Static load 23200 N
Rec max speed 3400 rpm
Weight 2.8 kg
Insert <a href="advanced_search_result.php?keywords=1050-1-3/4G+insonly">1050-1-3/4G Click Here</a>
Casting group 5
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
