SKU: MSF1.7/8-RHP

RHP MSF1-7/8 Imperial Four Bolt Square Cast Iron Flange Housing and 1-7/8 inch Bore Grub Screw Insert

RHP MSF1-7/8 Imperial Four Bolt Square Cast Iron Flange Housing and 1-7/8 inch Bore Grub Screw Insert

Out of stock


Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 1-7/8 inch
L 6.374 inch
H 5 inch
J 5.118 inch
G 0.625 inch
A 1.72 inch
A1 2.532 inch
A4 0.689 inch
B 2.187 inch
s 0.877 inch
d1 2.709 inch
Dynamic load cr 43500 N
Static load Cor 29200 N
Rec max speed 3100 rpm
Weight 4 kg
Insert <a href="advanced_search_result.php?keywords=1055-1-7/8G+insonly">1055-1-7/8G Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
