• SKF KMTA12 Precision Locking Nut with Locking Pins M60x1.5mm
1 1

SKU: KMTA12-SKF

SKF KMTA12 Precision Locking Nut with Locking Pins M60x1.5mm

SKF KMTA12 Precision Locking Nut with Locking Pins M60x1.5mm

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Precision KMTA Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation. The inclusion of 3 locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable
Brand / Quality:
SKF - High Quality
Thread Size:
M60x1.5
Technical
G M60x1.5
d2 84mm
d3 75mm
d4 62mm
B 24mm
J1 74.5mm
J2 13mm
N1 5.3mm
N2 6mm
Axial load capacity 380 kN
Loosening torque 150 Nm
Weight 0.49 kg
Spanner B80-90
Grub Screw M8
Screw torque 18 Nm
Name KMTA12
