• igubal KCLM10MH Left Hand Female Plastic Rod End 10mm Bore M10 Thread with Metal Insert
1 1

SKU: KCLM-10.MH

igubal KCLM10MH Left Hand Female Plastic Rod End 10mm Bore M10 Thread with Metal Insert

igubal KCLM10MH Left Hand Female Plastic Rod End 10mm Bore M10 Thread with Metal Insert
$27.33 ex VAT
$27.33 ex VAT
Sale Sold out

In stock

Price Break
4+ $12.96
9+ $12.23
19+ $12.09
29+ $11.94
39+ $11.80
49+ $11.65
59+ $10.92
69+ $10.78
79+ $10.63
89+ $10.48
99+ $10.19

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KCLM_MH_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M10
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
10mm
Technical
d1 10mm
d2 30mm
d3 M10
W SW15
B 14
mmC 10.5mm
h1 43mm
l3 22mm
l4 58mm
Max pivot angle 35°
Max static tensile strength (short term) 3100 N
Max static tensile strength (long term) 1500 N
Max radial load (short term) 800 N
Max radial load (long term) 400 N
Max torque strength inner threading 3 Nm
Weight 12.8 g
