SKU: KALM-20.MH.FINE
igubal KALM20MH Left Hand Male Plastic Rod End 20mm Bore M20x1.5 Fine Thread with Metal Insert - Allow 2-3 Days
igubal KALM20MH Left Hand Male Plastic Rod End 20mm Bore M20x1.5 Fine Thread with Metal Insert - Allow 2-3 Days
Regular price
$51.76
ex VAT
Regular price
Sale price
$51.76
ex VAT
In stock
Price Break
4+
$24.54
9+
$23.17
19+
$22.89
29+
$22.61
39+
$22.34
49+
$22.06
59+
$20.68
69+
$20.41
79+
$20.13
89+
$19.86
99+
$19.30
Quantity
Couldn't load pickup availability
Share this product
Description
Description
KALM_MH_DESC
- Brand / Quality:
- Igus - High Quality
- Thread Size:
- M20x1.5
- Thread M / F:
- Male
- Thread Direction:
- Left Hand
- Inside Diameter:
- 20mm
Technical
Technical
| d1 | 20mm |
|---|---|
| d2 | 50mm |
| d3 | M20x1.5 |
| C1 | 18mm |
| B | 25mm |
| h | 78mm |
| l1 | 45mm |
| l2 | 104mm |
| Max pivot angle | 23° |
| Max static tensile strength (short term) | 6000 N |
| Max static tensile strength (long term) | 3000 N |
| Max radial load (short term) | 1300 N |
| Max radial load (long term) | 650 N |
| Min thread depth | 32mm |
| Max torque strength outside thread | 25 Nm |
| Max torque through ball (standard) | 55 Nm |
| Max torque through ball (MH) | 200 Nm |
| Weight | 58 g |
