SKU: HGZ500-JCS
JCS HGZ500 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 470-500mm Band Width 13mm
JCS HGZ500 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 470-500mm Band Width 13mm
Out of stock
Share this product
Description
Description
Zinc Plated Steel Hi-Grip Worm Drive Hose Clips: Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, which has the highest requirements of any of the international standards and tests sealing ability, clamping force and torque.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 470mm
- Max Adjustment Range:
- 500mm
Technical
Technical
| BS No. | 500 |
|---|---|
| Adjustment Range (mm) | 470-500mm |
| Adjustment Range (inch) | 18-1/2 - 19-5/8 inch |
| A | 7mm |
| B | 20mm |
| C | 12mm |
| D | 16mm |
| E | 13mm |
| F | 0.9mm |
| Screw | 7mm A/F |
| Recommended Torque Nm | 6Nm |
| Recommended Torque lb-in | 54lb-in |
