• SKF C3224K Carb Toroidal Roller Bearing with Taper Bore 120x215x76mm Allow 7-10 Days
1 1

SKU: C3224K-SKF

SKF C3224K Carb Toroidal Roller Bearing with Taper Bore 120x215x76mm Allow 7-10 Days

SKF C3224K Carb Toroidal Roller Bearing with Taper Bore 120x215x76mm Allow 7-10 Days
$2,172.47 ex VAT
$2,172.47 ex VAT
Sale Sold out

In stock

Price Break
10+ $1,030.18
19+ $972.31
29+ $960.73
39+ $949.16
49+ $937.58
74+ $926.01
99+ $868.13
199+ $856.56
249+ $844.98
499+ $833.41
999+ $810.26

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
120mm
Outside Diameter:
215mm
Width:
76mm
Seals / Shields:
None
Technical
--- Dimensions
d 120mm
D 215mm
B 76mm
d2 149mm
D1 190mm
r1r2 min 2.1mm
s1 17.1mm
da min 132mm
da max 160mm
Da min 180mm
Da max 203mm
Ca 2.4mm
ra max 2mm
--- Speeds and Loads
Dynamic load C 750 kN
Static load Co 980 kN
Fatigue load limit Pu 98 kN
Reference speed 2400 rpm
Limiting speed 3200 rpm
--- Factors
Misalignment factor k1 0.103
Operating clearance factor k2 0.108
--- Weights
Weight 11.5 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H2324L+sleeve>H2324L</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HA2324L+sleeve>HA2324L</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX3224G+sleeve>AHX3224G</a>
