SKU: BB.53.MB
Major Brand BB53 Hexagon Section Double Sided V-Belt - Allow 2-3 Days
Out of stock
Share this product
Description
|
Hexagon profile V-Belts: Hex belts, also known as double V-belts, are designed for use on
drives with one or more reverse bends. They usually transmit power
from both sides of the belt.
To meet the multiple-bend and dual-power requirements, we build
Hex belts with rugged Vytacord tension members. They deliver
maximum strength with minimum elongation. They also work with
all the other quality materials that are a part of our Hex belts to
deliver maximum performance over a long, trouble-free life.
Hex belts are available in AA, BB, and CC cross sections. |
- Brand / Quality:
- Major Brand - High Quality
- Belt Number:
- BB53
- Inside Length Approx:
- 1346mm = 53 inch
- Outside Length Approx:
- 1408mm = 55.43 inch
- Belt Width Approx:
- 17mm
- Belt Depth Approx:
- 13mm
- Belt Datum Length Approx:
- 1395mm = 54.92 inch
Technical
| Reference Length | 1346mm = 53 inch |
|---|---|
| Datum Length | 1395mm = 54.92 inch |
