• NSK 7934CTRQUMP3 Super Precision Angular Contact Spindle Bearing 170x230x28mm (Set of 4)
1 1

SKU: 7934CTRQUMP3-NSK

NSK 7934CTRQUMP3 Super Precision Angular Contact Spindle Bearing 170x230x28mm (Set of 4)

NSK 7934CTRQUMP3 Super Precision Angular Contact Spindle Bearing 170x230x28mm (Set of 4)
$11,350.37 ex VAT
$11,350.37 ex VAT
Sale Sold out

In stock

Price Break
3+ $5,382.35
5+ $5,079.97
10+ $5,019.49
25+ $4,959.02
49+ $4,898.54
74+ $4,838.06
99+ $4,535.69
199+ $4,475.21
249+ $4,414.73
499+ $4,354.26
999+ $4,233.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
RGR72E2J9J
Brand / Quality:
NSK - High Quality
Inside Diameter:
170mm
Outside Diameter:
230mm
Width:
28mm
Seals / Shields:
None
Style:
Universal Matched Quad Bearing Set
Contact Angle:
15 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 170mm
D 230mm
B 28mm
r<sub>min</sub> 2mm
r1<sub>min</sub> 1mm
--- Loads angles and speeds
C<sub>r</sub> 118Kn
C<sub>or</sub> 148kN
Axial load Kn 88.5 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 16.8
Effective diameter 40.8mm
Max speed in grease 5300 rpm
Max speed in oil 8300 rpm
--- Fitting dimensions
d<sub>a min</sub> 180mm
D<sub>a max</sub> 220mm
D<sub>b max</sub> 224mm
r<sub>a max</sub> 2mm
r<sub>b max</sub> 1mm
Weight 13.44kg
