• NSK 7908CTRDULP3 Super Precision Angular Contact Spindle Bearing 40x62x12mm (Set of 2)
1 1

SKU: 7908CTRDULP3-NSK

NSK 7908CTRDULP3 Super Precision Angular Contact Spindle Bearing 40x62x12mm (Set of 2)

NSK 7908CTRDULP3 Super Precision Angular Contact Spindle Bearing 40x62x12mm (Set of 2)
$527.54 ex VAT
$527.54 ex VAT
Sale Sold out

In stock

Price Break
3+ $250.16
5+ $236.11
10+ $233.30
25+ $230.49
49+ $227.68
74+ $224.87
99+ $210.81
199+ $208.00
249+ $205.19
499+ $202.38
999+ $196.76

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
40mm
Outside Diameter:
62mm
Width:
12mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
15 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 40mm
D 62mm
B 12mm
r<sub>min</sub> 0.6mm
r1<sub>min</sub> 0.3mm
--- Loads angles and speeds
C<sub>r</sub> 15.9Kn
C<sub>or</sub> 11.7kN
Axial load Kn 8.4 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15.7
Effective diameter 12.8mm
Max speed in grease 22600 rpm
Max speed in oil 34400 rpm
--- Fitting dimensions
d<sub>a min</sub> 45mm
D<sub>a max</sub> 57mm
D<sub>b max</sub> 59.5mm
r<sub>a max</sub> 0.6mm
r<sub>b max</sub> 0.3mm
Weight 0.218kg
