• NSK 7907CTRQUMP3 Super Precision Angular Contact Spindle Bearing 35x55x10mm (Set of 4)
1 1

SKU: 7907CTRQUMP3-NSK

NSK 7907CTRQUMP3 Super Precision Angular Contact Spindle Bearing 35x55x10mm (Set of 4)

NSK 7907CTRQUMP3 Super Precision Angular Contact Spindle Bearing 35x55x10mm (Set of 4)
$889.27 ex VAT
$889.27 ex VAT
Sale Sold out

In stock

Price Break
3+ $413.42
5+ $390.20
10+ $385.55
25+ $380.91
49+ $376.26
74+ $371.62
99+ $348.39
199+ $343.74
249+ $339.10
499+ $334.45
999+ $325.16

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
RGR72E2J9J
Brand / Quality:
NSK - High Quality
Inside Diameter:
35mm
Outside Diameter:
55mm
Width:
10mm
Seals / Shields:
None
Style:
Universal Matched Quad Bearing Set
Contact Angle:
15 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 35mm
D 55mm
B 10mm
r<sub>min</sub> 0.6mm
r1<sub>min</sub> 0.3mm
--- Loads angles and speeds
C<sub>r</sub> 12.7Kn
C<sub>or</sub> 9.15kN
Axial load Kn 6.6 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15.7
Effective diameter 11mm
Max speed in grease 25600 rpm
Max speed in oil 38900 rpm
--- Fitting dimensions
d<sub>a min</sub> 40mm
D<sub>a max</sub> 50mm
D<sub>b max</sub> 52.5mm
r<sub>a max</sub> 0.6mm
r<sub>b max</sub> 0.3mm
Weight 0.296kg
