• NSK 7007A5TRDUMP3 Super Precision Angular Contact Spindle Bearing 35x62x14mm (Set of 2)
1 1

SKU: 7007A5TRDUMP3-NSK

NSK 7007A5TRDUMP3 Super Precision Angular Contact Spindle Bearing 35x62x14mm (Set of 2)

NSK 7007A5TRDUMP3 Super Precision Angular Contact Spindle Bearing 35x62x14mm (Set of 2)
$457.59 ex VAT
$457.59 ex VAT
Sale Sold out

In stock

Price Break
3+ $216.99
5+ $204.80
10+ $202.36
25+ $199.93
49+ $197.49
74+ $195.05
99+ $182.86
199+ $180.42
249+ $177.98
499+ $175.55
999+ $170.67

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
35mm
Outside Diameter:
62mm
Width:
14mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 35mm
D 62mm
B 14mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 19.1Kn
C<sub>or</sub> 13kN
Axial load Kn 11.4 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 18.3mm
Max speed in grease 20700 rpm
Max speed in oil 31000 rpm
--- Fitting dimensions
d<sub>a min</sub> 41mm
D<sub>a max</sub> 56mm
D<sub>b max</sub> 57mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.302kg
