SKU: 6202-2NKE-NACHI
NACHI 62022NKE Non Contact Low Friction Sealed Deep Groove Ball Bearing 15x35x11mm
NACHI 62022NKE Non Contact Low Friction Sealed Deep Groove Ball Bearing 15x35x11mm
Regular price
$13.74
ex VAT
Regular price
Sale price
$13.74
ex VAT
Equivalent to: 6202NKE
In stock
Price Break
5+
$6.52
9+
$6.15
19+
$6.08
29+
$6.00
49+
$5.93
74+
$5.86
99+
$5.49
199+
$5.42
249+
$5.35
499+
$5.27
999+
$5.13
Quantity
Couldn't load pickup availability
Description
Description
|
NACHI Non-contact Rubber Sealed Deep Groove Ball Bearings: These deep groove ball bearings can sustain radial, axial or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. This bearing has two non-contact rubber seals to provide a labyrinth clearance. Benefits: High-running accuracy and high-speed operation, good grease sealing, good protection against dust, low friction. |
- Brand / Quality:
- Nachi - High Quality
- Inside Diameter:
- 15mm
- Outside Diameter:
- 35mm
- Width:
- 11mm
- Seals / Shields:
- Low Friction
- Clearance:
- * Standard
Technical
Technical
| Inside Diameter d | 15mm |
|---|---|
| Outside Diameter D | 35mm |
| Width B | 11mm |
| Min radius r | 0.6mm |
| Dynamic load | 7650 kN |
| Static load | 3700 kN |
| Max speed | 20000 rpm |
| da min | 20mm |
| Da max | 30mm |
| ra max | 0.6mm |
| Weight | 0.045 kg |
