53324 Budget Single Thrust Ball Bearing with Spherical Housing Seat U324 120x210x80mm

Name: 53324 Budget Single Thrust Ball Bearing with Spherical Housing Seat U324 120x210x80mm
Brand: Gen
SKU: 53324+U324-EU
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 120mm
Outside Diameter:: 210mm
Width:: 80mm

Technical

d	120mm
D	210mm
H1	80mm
Dynamic load C	325 kN
Static load Co	980 kN
Fatigue load limit Pu	28.5 kN
Minimum load factor A	5
Reference speed	1100 rpm
Limiting Speed	1500 rpm
Weight	12.5 kg
Seating Washer	U324
d1	205mm
D1	123mm
D2	165mm
D3	220mm
H	74.1mm
C	22mm
R	160mm
s	63mm
r1r2 min	2.1mm
da max	173mm
Da max	165mm
ra max	2mm
