SKU: 53315?EU

53315 Budget Single Thrust Ball Bearing with Spherical Housing Seat U315 75x135x52mm

Name: 53315 Budget Single Thrust Ball Bearing with Spherical Housing Seat U315 75x135x52mm
Brand: Gen
SKU: 53315?EU
Price: 338.32 CAD
Availability: InStock

$338.32 ex VAT

Sale Sold out

In stock

Price Break

10+ $160.64

19+ $151.61

29+ $149.81

39+ $148.00

49+ $146.20

74+ $144.40

99+ $135.37

199+ $133.57

249+ $131.76

499+ $129.96

999+ $126.35

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 75mm
Outside Diameter:: 135mm
Width:: 52mm

Technical

d	75mm
D	135mm
H1	52mm
Dynamic load C	163 kN
Static load Co	390 kN
Fatigue load limit Pu	14 kN
Minimum load factor A	0.79
Reference speed	1700 rpm
Limiting Speed	2400 rpm
Weight	3.2 kg
Seating Washer	U315
d1	135mm
D1	77mm
D2	105mm
D3	140mm
H	48.1mm
C	15mm
R	100mm
s	37mm
r1r2 min	1.5mm
da max	111mm
Da max	105mm
ra max	1.5mm
