SKU: 53307?MB

53307 Budget Single Thrust Ball Bearing with Spherical Housing Seat U307 35x68x28mm

Name: 53307 Budget Single Thrust Ball Bearing with Spherical Housing Seat U307 35x68x28mm
Brand: Gen
SKU: 53307?MB
Price: 67.96 CAD
Availability: InStock

$67.96 ex VAT

Sale Sold out

In stock

Price Break

10+ $32.23

19+ $30.42

29+ $30.05

39+ $29.69

49+ $29.33

74+ $28.97

99+ $27.16

199+ $26.79

249+ $26.43

499+ $26.07

999+ $25.35

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 35mm
Outside Diameter:: 68mm
Width:: 28mm

Technical

d	35mm
D	68mm
H1	28mm
Dynamic load C	49.4 kN
Static load Co	96.5 kN
Fatigue load limit Pu	3.55 kN
Minimum load factor A	0.048
Reference speed	3200 rpm
Limiting Speed	4500 rpm
Weight	0.46 kg
Seating Washer	U307
d1	68mm
D1	37mm
D2	52mm
D3	72mm
H	25.6mm
C	7.5mm
R	56mm
s	24mm
r1r2 min	1mm
da max	55mm
Da max	52mm
ra max	1mm
