• 53306 Major Brand Single Thrust Ball Bearing with Spherical Housing Seat U306 30x60x25mm
1 1

SKU: 53306?MB

53306 Major Brand Single Thrust Ball Bearing with Spherical Housing Seat U306 30x60x25mm

53306 Major Brand Single Thrust Ball Bearing with Spherical Housing Seat U306 30x60x25mm
$108.78 ex VAT
$108.78 ex VAT
Sale Sold out

In stock

Price Break
10+ $51.59
19+ $48.69
29+ $48.11
39+ $47.53
49+ $46.95
74+ $46.37
99+ $43.47
199+ $42.89
249+ $42.31
499+ $41.73
999+ $40.57

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
30mm
Outside Diameter:
60mm
Width:
25mm
Technical
d 30mm
D 60mm
H1 25mm
Dynamic load C 37.7 kN
Static load Co 71 kN
Fatigue load limit Pu 2.65 kN
Minimum load factor A 0.026
Reference speed 3800 rpm
Limiting Speed 5300 rpm
Weight 0.33 kg
Seating Washer U306
d1 60mm
D1 32mm
D2 45mm
D3 62mm
H 22.6mm
C 7mm
R 50mm
s 22mm
r1r2 min 1mm
da max 48mm
Da max 45mm
ra max 1mm
