KSM 5201ZZ Metal Shielded Double Row Angular Contact Ball Bearing 12x32x15.9mm

Name: KSM 5201ZZ Metal Shielded Double Row Angular Contact Ball Bearing 12x32x15.9mm
Brand: KSM
SKU: 5201-ZZ-KSM
Price: 41.61 CAD
Availability: InStock

$41.61 ex VAT

Sale Sold out

Equivalent to: 3201ZZ

In stock

Price Break

4+ $19.73

9+ $18.62

19+ $18.40

29+ $18.18

49+ $17.96

99+ $17.74

179+ $16.63

249+ $16.41

499+ $16.18

699+ $15.96

999+ $15.52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Brand / Quality:: KSM - Good Quality
Inside Diameter:: 12mm
Outside Diameter:: 32mm
Width:: 15.9mm
Seals / Shields:: Metal Shielded

Technical

---	Bearing Dimensions
d	12mm
D	32mm
B	15.9mm
---	Abutment Dimensions
a	19mm
r1r2 min	0.6mm
r1r2 max	0.6mm
Da min	17mm
da max	27mm
---	Speeds, Weights and Loads
Basic Load Raiting Dynamic Cr	9150 N
Basic Static Load Raiting Cor	5050 N
Limiting Speed in Grease	15000 rpm
Limiting Speed in Oil	20000 rpm
Weight	0.057 kg
