SKU: 5200-ZZ-KSM

KSM 5200ZZ Metal Shielded Double Row Angular Contact Ball Bearing 10x30x14.3mm

Name: KSM 5200ZZ Metal Shielded Double Row Angular Contact Ball Bearing 10x30x14.3mm
Brand: KSM
SKU: 5200-ZZ-KSM
Price: 41.61 CAD
Availability: InStock

$41.61 ex VAT

Sale Sold out

Equivalent to: 3200ZZ

In stock

Price Break

4+ $19.73

9+ $18.62

19+ $18.40

29+ $18.18

49+ $17.96

99+ $17.74

179+ $16.63

249+ $16.41

499+ $16.18

699+ $15.96

999+ $15.52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Brand / Quality:: KSM - Good Quality
Inside Diameter:: 10mm
Outside Diameter:: 30mm
Width:: 14.3mm
Seals / Shields:: Metal Shielded

Technical

---	Bearing Dimensions
d	10mm
D	30mm
B	14.3mm
---	Abutment Dimensions
a	17.5mm
r1r2 min	0.6mm
r1r2 max	0.6mm
Da min	15mm
da max	25mm
---	Speeds, Weights and Loads
Basic Load Raiting Dynamic Cr	6950 N
Basic Static Load Raiting Cor	3800 N
Limiting Speed in Grease	16000 rpm
Limiting Speed in Oil	22000 rpm
Weight	0.049 kg
