SKU: 20326-MB-MB
20326MB Barrel Roller Bearing with Cylindrical Bore 130x280x58mm - Allow 2-3 Days
20326MB Barrel Roller Bearing with Cylindrical Bore 130x280x58mm - Allow 2-3 Days
Out of stock
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid brass cage. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures from -30 deg C to +150 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 130mm
- Outside Diameter:
- 280mm
- Width:
- 58mm
- Clearance:
- * Standard
Technical
Technical
| d | 130mm |
|---|---|
| D | 280mm |
| B | 58mm |
| r min | 4mm |
| D1 | 240.3mm |
| da min | 147mm |
| Da max | 263mm |
| ra max | 3mm |
| Dynamic Load Cr | 550000 N |
| Static Load C0r | 720000 N |
| Fatigue limit load Cur | 59000 N |
| Limiting speed nG | 1400 rpm |
| Weight | 18.4 kg |
