SKU: 20248-MB-MB
20248MB Barrel Roller Bearing with Cylindrical Bore 240x440x72mm - Allow 2-3 Days
20248MB Barrel Roller Bearing with Cylindrical Bore 240x440x72mm - Allow 2-3 Days
Out of stock
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid brass cage. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures from -30 deg C to +150 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 240mm
- Outside Diameter:
- 440mm
- Width:
- 72mm
- Clearance:
- * Standard
Technical
Technical
| d | 240mm |
|---|---|
| D | 440mm |
| B | 72mm |
| r min | 4mm |
| D1 | 388mm |
| da min | 257mm |
| Da max | 423mm |
| ra max | 3mm |
| Dynamic Load Cr | 1060000 N |
| Static Load C0r | 1600000 N |
| Fatigue limit load Cur | 129000 N |
| Limiting speed nG | 750 rpm |
| Weight | 50.5 kg |
