SKU: 20211-TVP-C3-MB
20211TVPC3 Barrel Roller Bearing with Cylindrical Bore 55x100x21mm - Allow 2-3 Days
20211TVPC3 Barrel Roller Bearing with Cylindrical Bore 55x100x21mm - Allow 2-3 Days
Regular price
$323.64
ex VAT
Regular price
Sale price
$323.64
ex VAT
In stock
Price Break
3+
$153.47
4+
$144.85
9+
$143.12
19+
$141.40
29+
$139.67
39+
$137.95
49+
$129.33
59+
$127.60
249+
$125.88
499+
$124.16
999+
$120.71
Quantity
Couldn't load pickup availability
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid window cage made from glass fibre reinforced polyamide. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures up to +120 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 100mm
- Width:
- 21mm
- Clearance:
- C3
Technical
Technical
| d | 55mm |
|---|---|
| D | 100mm |
| B | 21mm |
| r min | 1.5mm |
| D1 | 89.2mm |
| da min | 64mm |
| Da max | 91mm |
| ra max | 1.5mm |
| Dynamic Load Cr | 73500 N |
| Static Load C0r | 85000 N |
| Fatigue limit load Cur | 8700 N |
| Limiting speed nG | 3400 rpm |
| Weight | 0.653 kg |
