SKU: 06B-1-SYNO-100FT-RENOLD
Renold SYNO 06B-1 BS Simplex Roller Chain 3/8mm Pitch - 100 Feet Length Allow 2-3 Days
Renold SYNO 06B-1 BS Simplex Roller Chain 3/8mm Pitch - 100 Feet Length Allow 2-3 Days
Equivalent to: SNX06B-1
Out of stock
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Simplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 9.53mm = 0.375 (3/8) inch
Technical
Technical
| Pitch (A) | 0.375 inch |
|---|---|
| Pitch (A) | 9.525mm |
| Inside Width min (B) | 5.72mm |
| Roller Diameter max (C) | 6.35mm |
| Plate Height max (D) | 8.2mm |
| Plate Width Inner max (E) | 1.29mm |
| Plate Width Outer max (F) | 1.04mm |
| Pin Diameter max (G) | 3.28mm |
| Pin Length max (H1) | 12.5mm |
| Connecting link extension max (J) | 1.3mm |
| ISO606 Tensile strength min | 8900 N |
| Weight | 0.395 kg/m |
