SKU: WSZC12-JCS
JCS WSZC12 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 9.5-12mm Band Width 9mm
- Regular price
- $8.36 ex VAT
- Sale price
- $8.36
- Regular price
-
In stock
Quantity Price Breaks
3
$7.44
5
$7.02
9
$6.94
19
$6.86
49
$6.77
74
$6.69
99
$6.27
199
$6.19
249
$6.10
499
$6.02
999
$5.85
SKU:
WSZC12-JCS
JCS WSZC12 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 9.5-12mm Band Width 9mm
- Regular price
- $8.36 ex VAT
- Sale price
- $8.36
- Regular price
-
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
Technical
| BS No. | = | 12 |
| Adjustment Range (mm) | = | 9.5-12mm |
| Adjustment Range (inch) | = | 3/8 - 1/2 inch |
| A | = | 7mm |
| B | = | 31mm |
| C | = | 10mm |
| D | = | 12mm |
| E | = | 9mm |
| F | = | 0.7mm |
| G | = | 24mm |
| Recommended Torque Nm | = | 3Nm |
| Recommended Torque lb-in | = | 26lb-in |
