SKU: UCPX.12
UCPX12 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 60mm Bore Insert
- Regular price
- $150.94 ex VAT
- Sale price
- $150.94
- Regular price
-
In stock
Quantity Price Breaks
3
$134.34
4
$126.79
9
$125.28
19
$123.77
49
$122.26
99
$120.75
499
$113.21
999
$111.70
1999
$110.19
2999
$108.68
4999
$105.66
SKU:
UCPX.12
UCPX12 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 60mm Bore Insert
- Regular price
- $150.94 ex VAT
- Sale price
- $150.94
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 60mm |
| h | = | 76.2mm |
| a | = | 286mm |
| e | = | 203mm |
| b | = | 83mm |
| s2 | = | 41mm |
| s1 | = | 25mm |
| g | = | 32mm |
| w | = | 152mm |
| B1 | = | 65.1mm |
| n | = | 25.4mm |
| Bolt Size | = | M20 |
| Weight | = | 7.4 kg |
| Dynamic load | = | 4480 kgf |
| Static load | = | 3470 kgf |
