SKU: UCPX.11
UCPX11 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 55mm Bore Insert
- Regular price
- $115.01 ex VAT
- Sale price
- $115.01
- Regular price
-
In stock
Quantity Price Breaks
3
$102.36
4
$96.61
9
$95.46
19
$94.31
49
$93.16
99
$92.01
499
$86.26
999
$85.11
1999
$83.96
2999
$82.81
4999
$80.51
SKU:
UCPX.11
UCPX11 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 55mm Bore Insert
- Regular price
- $115.01 ex VAT
- Sale price
- $115.01
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 55mm |
| h | = | 69.8mm |
| a | = | 260mm |
| e | = | 184mm |
| b | = | 79mm |
| s2 | = | 36mm |
| s1 | = | 25mm |
| g | = | 30mm |
| w | = | 139mm |
| B1 | = | 65.1mm |
| n | = | 25.4mm |
| Bolt Size | = | M20 |
| Weight | = | 6.3 kg |
| Dynamic load | = | 4100 kgf |
| Static load | = | 3150 kgf |
| Rec max speed | = | 2800 rpm |
