SKU: UCPX.10
UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
- Regular price
- $137.18 ex VAT
- Sale price
- $137.18
- Regular price
-
In stock
Quantity Price Breaks
3
$122.09
4
$115.23
9
$113.86
19
$112.49
49
$111.12
99
$109.74
499
$102.89
999
$101.51
1999
$100.14
2999
$98.77
4999
$96.03
SKU:
UCPX.10
UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
- Regular price
- $137.18 ex VAT
- Sale price
- $137.18
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 50mm |
| h | = | 63.5mm |
| a | = | 241mm |
| e | = | 171mm |
| b | = | 73mm |
| s2 | = | 36mm |
| s1 | = | 20mm |
| g | = | 27mm |
| w | = | 126mm |
| B1 | = | 55.6mm |
| n | = | 22.2mm |
| Bolt Size | = | M16 |
| Weight | = | 4.4 kg |
| Dynamic load | = | 3400 kgf |
| Static load | = | 2550 kgf |
| Rec max speed | = | 3100 rpm |
