SKU: UCPX.08
UCPX08 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 40mm Bore Insert
- Regular price
- $61.75 ex VAT
- Sale price
- $61.75
- Regular price
-
In stock
Quantity Price Breaks
3
$54.96
4
$51.87
9
$51.25
19
$50.64
49
$50.02
99
$49.40
499
$46.31
999
$45.70
1999
$45.08
2999
$44.46
4999
$43.23
SKU:
UCPX.08
UCPX08 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 40mm Bore Insert
- Regular price
- $61.75 ex VAT
- Sale price
- $61.75
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 40mm |
| h | = | 58.7mm |
| a | = | 222mm |
| e | = | 156mm |
| b | = | 67mm |
| s2 | = | 32mm |
| s1 | = | 20mm |
| g | = | 26mm |
| w | = | 113mm |
| B1 | = | 49.2mm |
| n | = | 19mm |
| Bolt Size | = | M16 |
| Weight | = | 3.5 kg |
| Dynamic load | = | 2650 kgf |
| Static load | = | 1910 kgf |
| Rec max speed | = | 3700 rpm |
