SKU: UCPX.06
UCPX06 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 30mm Bore Insert
- Regular price
- $41.26 ex VAT
- Sale price
- $41.26
- Regular price
-
In stock
Quantity Price Breaks
3
$36.72
4
$34.66
9
$34.25
19
$33.83
49
$33.42
99
$33.01
499
$30.95
999
$30.53
1999
$30.12
2999
$29.71
4999
$28.88
SKU:
UCPX.06
UCPX06 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 30mm Bore Insert
- Regular price
- $41.26 ex VAT
- Sale price
- $41.26
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 30mm |
| h | = | 47.6mm |
| a | = | 175mm |
| e | = | 127mm |
| b | = | 57mm |
| s2 | = | 25mm |
| s1 | = | 17mm |
| g | = | 20mm |
| w | = | 94mm |
| B1 | = | 42.9mm |
| n | = | 17.5mm |
| Bolt Size | = | M12 |
| Weight | = | 2 kg |
| Dynamic load | = | 2010 kgf |
| Static load | = | 1390 kgf |
| Rec max speed | = | 4500 rpm |
