SKU: UCP.213-40
UCP213-40 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2-1/2 inch Bore Insert
- Regular price
- $127.31 ex VAT
- Sale price
- $127.31
- Regular price
-
In stock
Quantity Price Breaks
3
$113.31
4
$106.94
9
$105.67
19
$104.39
49
$103.12
99
$101.85
499
$95.48
999
$94.21
1999
$92.94
2999
$91.66
4999
$89.12
SKU:
UCP.213-40
UCP213-40 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2-1/2 inch Bore Insert
- Regular price
- $127.31 ex VAT
- Sale price
- $127.31
- Regular price
-
Description
|
UCP or NP Series Plummer / Pillow Housings: Supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required. Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 2-1/2 inch |
| h | = | 76.2mm |
| a | = | 265mm |
| e | = | 203mm |
| b | = | 70mm |
| s2 | = | 29mm |
| s1 | = | 25mm |
| g | = | 27mm |
| w | = | 150mm |
| B1 | = | 65.1mm |
| n | = | 25.4mm |
| Bolt Size | = | M20 |
| Weight | = | 5.7 kg |
| Dynamic load | = | 4480 kgf |
| Static load | = | 3470 kgf |
