SKU: TBS-T-16B-30
30 Tooth 16B Triplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
- Regular price
- $411.17 ex VAT
- Sale price
- $411.17
- Regular price
-
Not in stock
Quantity Price Breaks
5
$365.94
9
$345.38
19
$341.27
29
$337.16
49
$333.05
74
$328.94
99
$308.38
199
$304.27
249
$300.15
499
$296.04
999
$287.82
SKU:
TBS-T-16B-30
30 Tooth 16B Triplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain (Bush not Incl.)
- Regular price
- $411.17 ex VAT
- Sale price
- $411.17
- Regular price
-
Description
Tapered Bore Sprockets: Small sprockets are usually manufactured from C45 Steel and the large sprockets maybe supplied in G22 Cast Iron. These taper bore sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Technical
| Tooth Radius r3 | = | 26mm |
| Chamfer c | = | 2.5mm |
| Tooth Width b1 | = | 15.8mm |
| Tooth Width B1 | = | 16.2mm |
| Tooth Width B2 | = | 47.7mm |
| Tooth Width B3 | = | 79.6mm |
| Pitch | = | 25.4mm |
| Width Between Inner | = | 17.02mm |
| Roller Diameter | = | 15.88mm |
| No. of Teeth | = | 30 |
| Outer Diameter de | = | 254mm |
| Pitch Diameter dp | = | 243mm |
| Hub Diameter dm | = | 175mm |
| Length Through Bore A | = | 89mm |
| Reference | = | 83-30 |
| Taper Bush | = | < |
| a href=advanced_search_result.php?sort=2a& | = | search_in_description=1& |
| keywords=3535+tapered+locking+bush> | = | 3535 Click Here< |
| /a> | = |
