SKU: SSUCT.209
SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
- Regular price
- $328.20 ex VAT
- Sale price
- $328.20
- Regular price
-
Not in stock
Quantity Price Breaks
3
$292.10
4
$275.69
9
$272.41
19
$269.12
49
$265.84
99
$262.56
499
$246.15
999
$242.87
1999
$239.59
2999
$236.30
4999
$229.74
SKU:
SSUCT.209
SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
- Regular price
- $328.20 ex VAT
- Sale price
- $328.20
- Regular price
-
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 45mm |
| o | = | 19mm |
| g | = | 16mm |
| p | = | 83mm |
| q | = | 49mm |
| s | = | 29mm |
| b | = | 83mm |
| K | = | 16mm |
| e | = | 102mm |
| a | = | 117mm |
| w | = | 144mm |
| j | = | 49mm |
| l | = | 35mm |
| h | = | 87mm |
| Bi | = | 49.2mm |
| n | = | 19mm |
| Weight | = | 2.4 kg |
| Dynamic load | = | 2560 kgf |
| Static load | = | 1810 kgf |
| Rec max speed | = | 3700 rpm |
