SKU: SL087_NAK
NAK SL087 Hardened Stainless Sleeve for Shafts 49.12-49.28mm - Allow 7-10 Days
- Regular price
- $44.07 ex VAT
- Sale price
- $44.07
- Regular price
-
Not in stock
Quantity Price Breaks
10
$39.22
19
$37.02
29
$36.58
39
$36.14
49
$35.70
74
$35.26
99
$33.05
199
$32.61
249
$32.17
499
$31.73
999
$30.85
SKU:
SL087_NAK
NAK SL087 Hardened Stainless Sleeve for Shafts 49.12-49.28mm - Allow 7-10 Days
- Regular price
- $44.07 ex VAT
- Sale price
- $44.07
- Regular price
-
Description
NAK Wear-Pro Shaft Protection Sleeves: Wear-Pro Sleeves offer an excellent sealing surface for radial shaft seals whilst reducing costly shaft machining or maintenance. These sleeves can be used anywhere with a radial shaft seal, such as in industrial gearboxes, motors, pumps, reducers, construction, agricultural equipment and automotive parts.
Benefits: Simple and quick installation, cost-effective, high-grade surface
Technical
| Shaft Diameter Range (A) | = | 49.12-49.28mm |
| Nominal Shaft Diameter (A) | = | 49.23mm |
| Flange Diameter (D) | = | 56.4mm |
| Width on Shaft (X) | = | 14.3mm |
| Overall Width (Y) | = | 17.5mm |
| Installation Depth (Z) | = | 25.4mm |
| Flange Diameter (D) Tolerance | = | 1.6mm |
| Width on Shaft (X) Tolerance | = | 0.8mm |
| Overall Width (Y) Tolerance | = | 0.8mm |
