SKU: SL024_NAK
NAK SL024 Hardened Stainless Sleeve for Shafts 24.94-25.04mm - Allow 7-10 Days
- Regular price
- $41.17 ex VAT
- Sale price
- $41.17
- Regular price
-
Not in stock
Quantity Price Breaks
10
$36.64
19
$34.58
29
$34.17
39
$33.76
49
$33.35
74
$32.94
99
$30.88
199
$30.47
249
$30.05
499
$29.64
999
$28.82
SKU:
SL024_NAK
NAK SL024 Hardened Stainless Sleeve for Shafts 24.94-25.04mm - Allow 7-10 Days
- Regular price
- $41.17 ex VAT
- Sale price
- $41.17
- Regular price
-
Description
NAK Wear-Pro Shaft Protection Sleeves: Wear-Pro Sleeves offer an excellent sealing surface for radial shaft seals whilst reducing costly shaft machining or maintenance. These sleeves can be used anywhere with a radial shaft seal, such as in industrial gearboxes, motors, pumps, reducers, construction, agricultural equipment and automotive parts.
Benefits: Simple and quick installation, cost-effective, high-grade surface
Technical
| Shaft Diameter Range (A) | = | 24.94-25.04mm |
| Nominal Shaft Diameter (A) | = | 25mm |
| Flange Diameter (D) | = | 33mm |
| Width on Shaft (X) | = | 8mm |
| Overall Width (Y) | = | 11mm |
| Installation Depth (Z) | = | 50.8mm |
| Flange Diameter (D) Tolerance | = | 1.6mm |
| Width on Shaft (X) Tolerance | = | 0.8mm |
| Overall Width (Y) Tolerance | = | 0.8mm |
