Branded HF1616 Needle Roller Clutch Type One Way Bearing 16x22x16mm

SKU: HF.1616.MB

Branded HF1616 Needle Roller Clutch Type One Way Bearing 16x22x16mm

$25.01 ex VAT
$25.01
ex VAT
In stock

Quantity Price Breaks

10+ $22.26
19+ $21.01
29+ $20.76
39+ $20.51
49+ $20.26
74+ $20.01
99+ $18.76
199+ $18.51
249+ $18.26
499+ $18.01
999+ $17.51
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
Branded HF1616 Needle Roller Clutch Type One Way Bearing 16x22x16mm
SKU: HF.1616.MB

Branded HF1616 Needle Roller Clutch Type One Way Bearing 16x22x16mm

$25.01 ex VAT
$25.01
ex VAT

Description

Clutch Needle Roller Bearings: Designed to transmit torques in one direction and freewheel in the opposite direction. One-way clutches consist of a thin-walled, drawn outer ring with a series of ramps on the inside diameter, plastic cages, springs and needle rollers. They are supplied pre-greased with lithium soap grease.
They can be used together with needle roller bearings of the HK and BK series and are dimensionally the same and are available for shaft diameters from 6mm to 35mm
Benefits: High indexing accuracy, transmit torques in one direction, work at –10 deg C to +70 deg C

Please note: This bearing has a special none standard bore size

Technical

Fw = 16mm
D = 22mm
C = 16mm
Tolerance = 0.3mm
r min = 0.3
Torque = 20.5 N m
Speed (rotating shaft) = 8500 rpm
Speed (rotating outer ring) = 7500 rpm
Weight = 14 g
