INA GNE100XLKRRB Metric Spherical Outer Bearing Insert with R Seals and Eccentric Collar 100x215x109.4mm

SKU: GNE100-KRR-B-INA

INA GNE100XLKRRB Metric Spherical Outer Bearing Insert with R Seals and Eccentric Collar 100x215x109.4mm

$1,068.20 ex VAT
$1,068.20
ex VAT
Not in stock

Quantity Price Breaks

3 $950.70
5 $897.29
10 $886.61
15 $875.92
20 $865.24
30 $854.56
40 $801.15
50 $790.47
60 $779.79
75 $769.10
100 $747.74
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
INA GNE100XLKRRB Metric Spherical Outer Bearing Insert with R Seals and Eccentric Collar 100x215x109.4mm
SKU: GNE100-KRR-B-INA

INA GNE100XLKRRB Metric Spherical Outer Bearing Insert with R Seals and Eccentric Collar 100x215x109.4mm

$1,068.20 ex VAT
$1,068.20
ex VAT

Description

INA GNE..KRR-B Series Inserts: Bearing insert with spherical outer race, R seals and eccentric locking collar. These radial insert ball bearings are located on the shaft by means of a locking collar. They are particularly suitable for bearing arrangements with a constant direction of rotation, or under low speed and load, for an alternating direction of rotation. The inner rings of the bearings up to 60mm inside diameter, and locking collar in general, have a Corrotect® coating and are thus protected against fretting corrosion. The outer ring has two lubrication holes as standard. Operating temperature range: -20 deg C to +120 deg C.
Benefits: Can be re-lubricated, compensation of misalignment.
