SKU: 80-2-BB-NO12-RENOLD
Renold Blue Box 80-2-NO12 ANSI / AS Duplex Chain Single Cranked Cottered Link 1 inch Pitch
- Regular price
- $110.94 ex VAT
- Sale price
- $110.94
- Regular price
-
Not in stock
Quantity Price Breaks
2
$98.74
5
$93.19
10
$92.08
29
$90.97
49
$89.86
75
$88.75
100
$83.21
200
$82.10
250
$80.99
500
$79.88
1000
$77.66
SKU:
80-2-BB-NO12-RENOLD
Renold Blue Box 80-2-NO12 ANSI / AS Duplex Chain Single Cranked Cottered Link 1 inch Pitch
- Regular price
- $110.94 ex VAT
- Sale price
- $110.94
- Regular price
-
Description
| Renold No. 12 ANSI Duplex Connecting Link: A single link with cranked plates pressed onto a bush and roller assemble at the narrow end. A clearance fit connecting pin (No. 128) is fitted at the wide end and is secured by a split pin. |
Technical
| Pitch (A) | = | 1 inch |
| Pitch (A) | = | 25.4mm |
| Inside Width min (B) | = | 15.75mm |
| Roller Diameter max (C) | = | 15.88mm |
| Plate Height max (D) | = | 24.13mm |
| Plate Width Inner max (E) | = | 3.25mm |
| Plate Width Outer max (F) | = | 3.25mm |
| Pin Diameter max (G) | = | 7.94mm |
| Pin Length max (H2) | = | 61.9mm |
| Connecting Link Extension max (J) | = | 3mm |
| Transverse Pitch nom (K) | = | 29.29mm |
| ISO606 Tensile Strength min | = | 111200 N |
| Weight | = | 0.04kg/m |
