FAG 62012RSR Rubber Sealed Deep Groove Ball Bearing 12x32x10mm
FAG
FAG 62012RSR Rubber Sealed Deep Groove Ball Bearing 12x32x10mm
FAG

SKU: 6201-2RSR-FAG

FAG 62012RSR Rubber Sealed Deep Groove Ball Bearing 12x32x10mm

$10.26 ex VAT
$10.26
ex VAT
Equivalent to: 6201NSE 6201DU 6201RS 6201RSH 6201P 6201RSR 6201LU 62012NSE 6201DDU 62012RS 62012RS1 62012RSH 6201PP 6201LLU
In stock

Quantity Price Breaks

10+ $9.13
19+ $8.62
29+ $8.52
39+ $8.41
49+ $8.31
74+ $8.21
99+ $7.70
199+ $7.59
249+ $7.49
499+ $7.39
999+ $7.18
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
FAG 62012RSR Rubber Sealed Deep Groove Ball Bearing 12x32x10mm
FAG
SKU: 6201-2RSR-FAG

FAG 62012RSR Rubber Sealed Deep Groove Ball Bearing 12x32x10mm

$10.26 ex VAT
$10.26
ex VAT

Description

FAG Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing
Seals can be easily removed for applications that only require 1 seal.
Benefits: Prevents moisture and dirt getting into the bearing, lubricated for life

Technical

d = 12mm
D = 32mm
B = 10mm
Dynamic load C = 7.28 kN
Static load Co = 3.1 kN
Fatigue load limit Pu = 0.132 kN
Reference speed = 50000 rpm
Limiting speed = 15000 rpm
Mass = 0.037 kg
d1 = 18.5mm
D2 = 27.4mm
r1r2 min = 0.6mm
da min = 16.2
