SKF 618032RS1 Rubber Sealed Thin Section Deep Groove Ball Bearing 17x26x5mm

SKU: 61803-2RS1-SKF

SKF 618032RS1 Rubber Sealed Thin Section Deep Groove Ball Bearing 17x26x5mm

$29.57 ex VAT
$29.57
ex VAT
Equivalent to: 61803NSE 61803DU 61803RS 61803RSH 61803P 61803RSR 61803LU 6803NSE 6803DU 6803RS 6803RSH 6803P 6803RSR 6803LU 618032NSE 61803DDU 618032RS 618032RSH 61803PP 618032RSR 61803LLU
In stock

Quantity Price Breaks

10+ $26.32
19+ $24.84
29+ $24.54
39+ $24.25
49+ $23.95
74+ $23.66
99+ $22.18
199+ $21.88
249+ $21.59
499+ $21.29
999+ $20.70
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
SKF 618032RS1 Rubber Sealed Thin Section Deep Groove Ball Bearing 17x26x5mm
SKU: 61803-2RS1-SKF

SKF 618032RS1 Rubber Sealed Thin Section Deep Groove Ball Bearing 17x26x5mm

$29.57 ex VAT
$29.57
ex VAT

Description

Thin Section Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing.
Seals can be easily removed for applications that only require 1 seal.
Benefits: Prevents moisture and dirt getting into the bearing, lubricated for life, cost effective solution

Technical

d = 17mm
D = 26mm
B = 5mm
Dynamic load C = 1.68 kN
Static load Co = 0.93 kN
Fatigue load limit Pu = 0.039 kN
Reference speed = 56000 rpm
Limiting speed = 16000 rpm
Weight = 0.164 kg
d2 = 19.3mm
D2 = 24.1mm
r1r2 min = 0.3mm
da min = 19mm
da max = 19.2mm
Da max = 24mm
ra max = 0.3mm
Calculation factor kr = 0.015
Calculation factor f0 = 10
