Major Branded 618012RSRC3 Rubber Sealed Thin Deep Groove Ball Bearing 12x21x5mm

SKU: 61801-2RSR/C3-MB

Major Branded 618012RSRC3 Rubber Sealed Thin Deep Groove Ball Bearing 12x21x5mm

$34.19 ex VAT
$34.19
ex VAT
Equivalent to: 61801NSEC3 61801DUC3 61801RSC3 61801RSHC3 61801PC3 61801RSRC3 61801LUC3 6801NSEC3 6801DUC3 6801RSC3 6801RSHC3 6801PC3 6801RSRC3 6801LUC3 618012NSEC3 61801DDUC3 618012RSC3 618012RS1C3 618012RSHC3 61801PPC3 61801LLU 68012NSEC3 6801DDUC3 68012RSC3 68012RS1C3 68012RSHC3 6801PPC3 68012RSRC3 6801LLUC3
In stock

Quantity Price Breaks

10+ $30.43
19+ $28.72
29+ $28.38
39+ $28.04
49+ $27.69
74+ $27.35
99+ $25.64
199+ $25.30
249+ $24.96
499+ $24.62
999+ $23.93
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
Major Branded 618012RSRC3 Rubber Sealed Thin Deep Groove Ball Bearing 12x21x5mm
SKU: 61801-2RSR/C3-MB

Major Branded 618012RSRC3 Rubber Sealed Thin Deep Groove Ball Bearing 12x21x5mm

$34.19 ex VAT
$34.19
ex VAT

Description

Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing
Seals can be easily removed for applications that only require 1 seal.
Benefits: Prevents moisture and dirt getting into the bearing, lubricated for life

Technical

d = 12mm
D = 21mm
B = 5mm
Dynamic load C = 1.43 kN
Static load Co = 0.67 kN
Fatigue load limit Pu = 0.028 kN
Reference speed = 70000 rpm
Limiting speed = 20000 rpm
Mass = 0.0063 kg
d1 = 15.5mm
D2 = 21.4mm
r1r2 min = 0.3mm
da min = 14
