SKU: 53320+U320-SKF
SKF 53320 Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm
- Regular price
- $1,310.48 ex VAT
- Sale price
- $1,310.48
- Regular price
-
Not in stock
Quantity Price Breaks
10
$1,166.33
19
$1,100.80
29
$1,087.70
39
$1,074.59
49
$1,061.49
74
$1,048.38
99
$982.86
199
$969.76
249
$956.65
499
$943.55
999
$917.34
SKU:
53320+U320-SKF
SKF 53320 Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm
- Regular price
- $1,310.48 ex VAT
- Sale price
- $1,310.48
- Regular price
-
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
Technical
| d | = | 100mm |
| D | = | 170mm |
| H1 | = | 64mm |
| Dynamic load C | = | 229 kN |
| Static load Co | = | 610 kN |
| Fatigue load limit Pu | = | 19.6 kN |
| Minimum load factor A | = | 1.9 |
| Reference speed | = | 1400 rpm |
| Limiting speed | = | 1900 rpm |
| Weight | = | 5.95 kg |
| Seating washer | = | U320 |
| d1 | = | 170mm |
| D1 | = | 103mm |
| D2 | = | 135mm |
| D3 | = | 175mm |
| H | = | 59.2mm |
| C | = | 18mm |
| R | = | 125mm |
| s | = | 46mm |
| r1r2 min | = | 1.5mm |
| da max | = | 142mm |
| Da max | = | 135mm |
| ra max | = | 1.5mm |
