SKU: 5311-ZZ-KSM
KSM 5311ZZ Metal Shielded Double Row Angular Contact Ball Bearing 55x120x49.2mm
- Regular price
- $141.58 ex VAT
- Sale price
- $141.58
- Regular price
-
Not in stock
Quantity Price Breaks
4
$126.01
9
$118.93
19
$117.51
29
$116.10
49
$114.68
99
$113.26
179
$106.19
249
$104.77
499
$103.35
699
$101.94
999
$99.11
SKU:
5311-ZZ-KSM
KSM 5311ZZ Metal Shielded Double Row Angular Contact Ball Bearing 55x120x49.2mm
- Regular price
- $141.58 ex VAT
- Sale price
- $141.58
- Regular price
-
Description
|
Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well. Benefits: Compact, rigid, accommodates tilting, radial and axial loads |
Technical
| --- | = | Bearing Dimensions |
| d | = | 55mm |
| D | = | 120mm |
| B | = | 49.2mm |
| --- | = | Abutment Dimensions |
| a | = | 73mm |
| r1r2 min | = | 2mm |
| r1r2 max | = | 2mm |
| Da min | = | 65mm |
| da max | = | 110mm |
| --- | = | Speeds, Weights and Loads |
| Basic Load Raiting Dynamic Cr | = | 106000 N |
| Basic Static Load Raiting Cor | = | 82000 N |
| Limiting Speed in Grease | = | 3300 rpm |
| Limiting Speed in Oil | = | 1100 rpm |
| Weight | = | 2.32 kg |
