SKU: 10B-3-SYN-XXX-RENOLD_10FT
Renold Synergy 10B-3 BS Triplex Roller Chain 5/8 inch Pitch
- Regular price
- $1,561.10 ex VAT
- Sale price
- $1,561.10
- Regular price
-
Not in stock
Quantity Price Breaks
0
$1,389.38
SKU:
10B-3-SYN-XXX-RENOLD_10FT
Renold Synergy 10B-3 BS Triplex Roller Chain 5/8 inch Pitch
Length: 10 feet
- Regular price
- $1,561.10 - $3,892.82 ex VAT
- Sale price
- $1,561.10 - $3,892.82
- Regular price
-
Description
Renold Synergy High Performance Chain: Renold Synergy chain will last three times longer in normal working conditions than your current non-Renold chain or your next chain is free. It's that simple. If the working life of your non Renold Chain is unsatisfactory, try Renold Synergy®. You will see productivity increase, downtime cut and costs saved. Renold are so confident that their chain will significantly outlast any other non-Renold brand chain that we will give you a replacement chain free*. There has never been a better time to specify Renold Synergy® - the only high performance transmission chain.
* Subject to site visit from a Renold Service Engineer
Renold Synergy® has transformed the productivity and efficiency of all these industrial applications and more.
Technical
| Pitch (A) | = | 0.625 inch |
| Pitch (A) | = | 15.875mm |
| Inside Width min (B) | = | 9.65mm |
| Roller Diameter max (C) | = | 10.16mm |
| Plate Height max (D) | = | 14.6mm |
| Plate Width Inner max (E) | = | 1.55mm |
| Plate Width Outer max (F) | = | 1.55mm |
| Pin Diameter max (G) | = | 5.08mm |
| Pin Length max (H1) | = | 52mm |
| Connecting Link Extension max (J) | = | 2.5mm |
| ISO606 Tensile Strength min | = | 66700 N |
| Weight | = | 2.54kg/m |
