SKU: 100-3-SYNERGY-10FT-RENOLD
Renold Synergy 100-3 ANSI / AS Triplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
- Regular price
- $4,813.79 ex VAT
- Sale price
- $4,813.79
- Regular price
-
In stock
Quantity Price Breaks
10+
$4,284.27
19+
$4,043.58
29+
$3,995.45
39+
$3,947.31
49+
$3,899.17
74+
$3,851.03
99+
$3,610.34
199+
$3,562.20
249+
$3,514.07
499+
$3,465.93
999+
$3,369.65
SKU:
100-3-SYNERGY-10FT-RENOLD
Renold Synergy 100-3 ANSI / AS Triplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
- Regular price
- $4,813.79 ex VAT
- Sale price
- $4,813.79
- Regular price
-
Description
Renold Synergy High Performance Chain: Renold Synergy chain will last three times longer in normal working conditions than your current non-Renold chain or your next chain is free. It's that simple. If the working life of your non Renold Chain is unsatisfactory, try Renold Synergy®. You will see productivity increase, downtime cut and costs saved. Renold are so confident that their chain will significantly outlast any other non-Renold brand chain that we will give you a replacement chain free*. There has never been a better time to specify Renold Synergy® - the only high performance transmission chain.
* Subject to site visit from a Renold Service Engineer
Renold Synergy® has transformed the productivity and efficiency of all these industrial applications and more.
Technical
| Pitch (A) | = | 1.25 inch |
| Pitch (A) | = | 31.75mm |
| Inside Width min (B) | = | 18.9mm |
| Roller Diameter max (C) | = | 19.05mm |
| Plate Height max (D) | = | 30.17mm |
| Plate Width Inner max (E) | = | 4.06mm |
| Plate Width Outer max (F) | = | 4.06mm |
| Pin Diameter max (G) | = | 9.54mm |
| Pin Length max (H1) | = | 111.2mm |
| Connecting Link Extension max (J) | = | 4.2mm |
| ISO606 Tensile Strength min | = | 261000 N |
| Weight | = | 12.6kg/m |
